ISUZU 32t Refrigerated Truck
Long-haul temperature-controlled transport of fresh, frozen and pharmaceutical cargo
ISUZU 32t Refrigerated Truck
The QL5320XLCW6VDHJ is a heavy refrigerated truck built on a QINGLING (ISUZU) QL1320W6VDHY chassis at 32,000 kg GVW, with a 9,550 × 2,420 × 2,370 mm insulated body and 17,220 kg rated payload. Body glass-fibre reinforced panels with polyurethane insulation and a sealed, non-opening roof keep temperature stable on long-haul runs. This is the model for cross-border and inter-city cold chain, frozen seafood, meat and vaccine logistics; multi-temperature compartments and a standby electric refrigeration unit are available.
Specifications
Vehicle Announcement Data
| Model | QL5320XLCW6VDHJ |
|---|---|
| Product Name | Refrigerated truck |
| Product Brand | QINGLING |
| Announcement Batch | Batch No. 375 |
| Gross Vehicle Weight | 32,000 kg |
| Rated Payload | 17,220 kg |
| Kerb Weight | 14,650 kg |
| Overall Dimensions | 12,000×2,600×3,990 mm |
| Cargo Body Inner Dimensions | 9,550×2,420×2,370 mm |
| Axle Load | 6,500 / 6,500 / 19,000 kg (tandem axle group) |
| Max. Speed | 100 km/h (speed limited to 89 km/h optionally with the chassis) |
| Cab Seating Capacity | 2 persons |
| Approach / Departure Angle | 17° / 10° |
| Front / Rear Overhang | 1,370 / 2,835 mm |
Chassis Configuration
| Chassis Model | QL1320W6VDHY |
|---|---|
| Chassis Designation | Cargo truck chassis |
| Chassis Brand | ISUZU |
| Chassis Manufacturer | Qingling Motors Co., Ltd. |
| Wheelbase | 1,850+4,575+1,370 mm |
| Axles / Tyres | 4 axles / 12 tyres |
| Tyre Size | 12R22.5 16PR |
| Leaf Spring Count | 3/3/-/- |
| Front Track | 2,060 / 2,060 mm |
| Rear Track | 1,855 / 1,855 mm |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2018 China VI |
Van Body & Special Configuration
| Van Body Structure | Fully enclosed refrigerated body; roof sealed and non-openable |
|---|---|
| Cargo Body Inner Dimensions | 9,550×2,420×2,370 mm |
| Refrigeration Unit | A refrigeration unit of equivalent capacity from a different manufacturer can be specified |
| Side Door | May be supplied without a side door |
| Guards | Side guard: Q235 steel plate, bolted to the body cross-members. Rear under-run guard: SAPH440 steel plate (2.0 mm thick), section 190 × 50 mm, ground clearance 480 mm |
| ABS System | ABS8.8 ECU 24V (Knorr-Bremse Commercial Vehicle Brake Systems (Shiyan) Co., Ltd.) |
| Other Configuration | Fitted with GNSS tachograph; ETC on-board unit optional |
Engine
| Engine Model | 6WG1-TCG61 |
|---|---|
| Manufacturer | Isuzu (China) Engine Co., Ltd. |
| Displacement | 15,681 ml |
| Power | 338 kW (net power 337 kW) |
| Fuel Consumption | 38.01 L/100km |
Note: Data shown is taken from the published vehicle announcement for this model. Configuration varies by order; the specification sheet issued with the quotation prevails.
