HOWO 12t Refrigerated Truck
Temperature-controlled transport of fresh and frozen food and other cargo requiring a controlled temperature
HOWO 12t Refrigerated Truck
The CL5120XLC6GL is a 12-tonne refrigerated truck on a HOWO ZZ1127H4515F1 cargo chassis from Sinotruk Jinan Commercial Vehicle, running 2 axles and 6 tyres with wheelbases from 3,280 to 4,500 mm, at an 11,995 kg gross vehicle weight, 5,840 kg kerb weight and 5,960 kg rated payload. The insulated body measures 4,700 / 5,200 × 2,350 × 2,350 mm with a sealed, non-opening roof; aluminium floor rails for air circulation and a meat-rail body are available, and refrigeration units of the same rated capacity can be supplied in different models. Engine options include the Weichai WP3NQ160E61 and WP4.1NQ190E61 among others, covering 110–162 kW and meeting China VI (GB17691-2018) — a configuration for urban cold-chain distribution and medium-distance frozen food haulage.
Specifications
Vehicle Announcement Data
| Model | CL5120XLC6GL |
|---|---|
| Product Name | Refrigerated truck |
| Product Brand | CHENGLI |
| Announcement Batch | Batch No. 391 |
| Gross Vehicle Weight | 11,995 kg |
| Rated Payload | 5,960 kg |
| Kerb Weight | 5,840 kg |
| Overall Dimensions | 6,995 / 7,445 × 2,560 × 3,650 / 3,750 mm |
| Cargo Body Inner Dimensions | 4,700 / 5,200 × 2,350 × 2,350 mm |
| Axle Load | 4,285 / 7,710 kg |
| Max. Speed | 95 / 80 km/h |
| Cab Seating Capacity | 3 persons |
| Approach / Departure Angle | 18° / 14°, 18° / 13°, 17° / 12°, 17° / 11° |
| Front / Rear Overhang | 1,180 / 2,065, 1,240 / 2,005, 1,180 / 2,015, 1,240 / 1,955 mm |
Chassis Configuration
| Chassis Model | ZZ1127H4515F1 |
|---|---|
| Chassis Designation | Cargo truck chassis |
| Chassis Brand | HOWO |
| Chassis Manufacturer | Sinotruk Jinan Commercial Vehicle Co., Ltd. |
| Wheelbase | 3,280 – 4,500 mm (including 3,280 / 3,300 / 3,360 / 3,600 / 3,800 / 4,200 / 4,500 mm and other variants) |
| Axles / Tyres | 2 axles / 6 tyres |
| Tyre Size | 245/70R19.5 16PR, 8.25R20 16PR, 255/70R22.5 16PR, 9R22.5 14PR |
| Leaf Spring Count | 3/3+2, 2/2+1, 2/2+2, 3/4+3, 2/3+2, 1/1+1, 11/9+7, 11/11+7, 9/12+9, 3/5+3, 8/9+6, 3/8+6, 8/9+7 |
| Front Track | 1,776, 1,800, 1,820, 1,490, 1,582 mm |
| Rear Track | 1,555, 1,595, 1,695, 1,795, 1,576, 1,505 mm |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2018 China VI |
Van Body & Special Configuration
| Van Body Structure | Sealed, non-opening roof |
|---|---|
| Cargo Body Inner Dimensions | 4,700 / 5,200 × 2,350 × 2,350 mm |
| Side & Rear Guards | Side and rear guards are Q235A carbon steel; the side guard is welded and the rear guard is bolted; rear guard section 100 × 50 mm, lower edge 445 mm above ground |
| Optional Configuration | Optional aluminium floor rails for air circulation and meat-rail body; optional rear section appearance; refrigeration units of the same rated capacity in different models; optional direct-supply ETC on-board unit |
| Tail Lift (optional) | Tail lift stowed horizontal length 300 mm, tail lift weight 420 kg; when the tail lift is fitted the rear guard is Q235A carbon steel, bolted, section Φ100 mm, lower edge 500 mm above ground |
| Speed Limiter | Optional speed limiter, limited to 80 km/h |
| ABS System | XH-KQ4S4M-E01 (Guangzhou Xihe Automotive Electronic Equipment Co., Ltd.), CM4XL-4S/4M (Guangzhou Ruili Kemi Automotive Electronics Co., Ltd.), VIE ABS-Ⅱ (Zhejiang Wan'an Technology Co., Ltd.) |
Engine
| Engine Model | WP3NQ160E61, WP4.1NQ190E61, WP4.6NQ220E61 and other models |
|---|---|
| Manufacturer | Weichai Power Co., Ltd. |
| Displacement | 2,445 – 4,580 ml |
| Power Range | 110 – 162 kW |
| Fuel Consumption | 19.32 – 19.55 L/100km (by engine model) |
Note: Data shown is taken from the published vehicle announcement for this model. Configuration varies by order; the specification sheet issued with the quotation prevails.
