JIEFANG 25t Dropside Cargo Truck
Road transport of bulk and general cargo — building materials, engineering supplies and consumer goods
JIEFANG 25t Dropside Cargo Truck
The CA1252P26K2L7T3E6A80 is a 25-tonne dropside cargo truck on a JIEFANG chassis with 3 axles and 8 tyres, offering body lengths from 7,700 to 9,500 mm and a rated payload of 13,645 – 14,770 kg depending on the body. Overall dimensions range from 10,200 to 11,995 mm in length. Dropside panels make loading and unloading easy from either side with a forklift or by hand — the standard choice for building materials, agricultural produce and general freight. Body height, board material, tarpaulin frame and cab spec are configurable.
Specifications
Vehicle Announcement Data
| Model | CA1252P26K2L7T3E6A80 |
|---|---|
| Product Name | Dropside Cargo Truck |
| Product Brand | JIEFANG |
| Announcement Batch | Batch No. 407 |
| Gross Vehicle Weight | 25,000 kg |
| Kerb Weight | 10,100 / 10,680 / 11,160 kg |
| Rated Payload | 13,645 / 13,710 / 14,125 / 14,190 / 14,705 / 14,770 kg |
| Overall Dimensions | 10,200 – 11,995×2,550×3,300 – 3,950 mm |
| Cargo Body Dimensions | 7,700 – 9,500×2,400 / 2,450×600 / 800 mm |
| Axle Load | 6,750 / 6,750 / 11,500 kg |
| Max. Speed | 89 / 110 km/h |
| Cab Seating Capacity | 2 / 3 persons |
| Approach / Departure Angle | 19° / 12° |
| Front / Rear Overhang | 1,495 / 1,515 / 2,085 – 3,000 mm |
Chassis Configuration
| Chassis Model | CA1252P26K2L7T3E6A80 |
|---|---|
| Chassis Designation | Cargo truck chassis |
| Chassis Brand | JIEFANG |
| Chassis Manufacturer | China FAW Group Co., Ltd. |
| Wheelbase | 4,500 + 1,250 mm |
| Axles / Tyres | 3 axles / 8 tyres |
| Tyre Size | 11.00R20 18PR, 12R22.5 18PR, 295/80R22.5 18PR |
| Leaf Spring Count | 3/3/10+9, 9/9/10+9, 2/2/3+3 |
| Front Track | 2,020 / 2,042 / 2,072 mm |
| Rear Track | 1,878 / 1,900 mm |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2018 China VI |
| Braking System | ABS: Changchun Kemi CM4XL / Zhejiang Wan'an VIE ABS-II |
Superstructure & Guards
| Cargo Body Type | Dropside cargo body (side board height 600 / 800 mm) |
|---|---|
| Side Guard | Q235 steel, bolted |
| Rear Under-Run Guard | SS400 steel, bolted; section 125 × 115 mm, ground clearance 390 mm |
| Speed Limiter & Recording | Speed limiter optional (89 km/h); GNSS tachograph fitted |
| Optional Configuration | Flat-roof cab, A/C position, alternative bumper / mirror / fender / step structures, new front-face cab, cab livery, alternative cargo body structures, chassis layout, after-treatment cover, ETC on-board unit |
| Production Note | Superstructure may be fitted by an authorised subcontractor |
Engine
| Optional Engines | CA6DM2-46E66, CA6DM2-48E66 (China FAW Group Co., Ltd.) |
|---|---|
| Displacement | 11,050 ml |
| Power | 341 / 356 kW |
| Fuel Consumption | 27.0 L/100 km (for CA6DM2-46E66 / CA6DM2-48E66) |
Note: Data shown is taken from the published vehicle announcement for this model. Configuration varies by order; the specification sheet issued with the quotation prevails.
