JIANGXI ISUZU 4.5t Dropside Cargo Truck (Double Cab)
Urban delivery and short-to-medium haul of consumer goods, building materials and agricultural supplies
JIANGXI ISUZU 4.5t Dropside Cargo Truck (Double Cab)
The JXW1040CSJD2 is a light 4.5-tonne double-cab dropside truck on a JIANGXI ISUZU JXW1040CSJ2 chassis, with a body up to 3,160 × 2,100 × 440 mm and a rated payload of 1,540 / 1,605 kg. The double cab carries the crew, while the low 4,495 kg GVW keeps it inside light-truck licensing and toll classes in most markets — a practical last-mile and inter-city delivery vehicle. Cargo body height, board thickness and refrigeration or box-body conversions are available.
Specifications
Vehicle Announcement Data
| Model | JXW1040CSJD2 |
|---|---|
| Product Name | Dropside Cargo Truck |
| Product Brand | JIANGXI ISUZU |
| Announcement Batch | Batch No. 406 |
| Gross Vehicle Weight | 4,495 kg |
| Rated Payload | 1,540 / 1,605 kg |
| Kerb Weight | 2,565 kg |
| Overall Dimensions | 5,995×1,960 – 2,190×2,400 mm |
| Cargo Body Inner Dimensions | 3,160 × 1,880 – 2,100 × 380 – 440 mm (L × W × side board height) |
| Axle Load | 1,725 / 2,770 kg |
| Max. Speed | 100 km/h |
| Cab Seating Capacity | 2+3 / 3+3 persons (double cab) |
| Approach / Departure Angle | 20° / 16° |
| Front / Rear Overhang | 1,090 / 1,545 mm |
Chassis Configuration
| Chassis Model | JXW1040CSJ2 |
|---|---|
| Chassis Designation | Cargo truck chassis |
| Chassis Brand | JIANGXI ISUZU |
| Chassis Manufacturer | Jiangxi Isuzu Motors Co., Ltd. |
| Wheelbase | 3,360 mm |
| Axles / Tyres | 2 axles / 6 tyres |
| Tyre Size | 7.00R16LT 8PR / 10PR |
| Leaf Spring Count | 2/2+1, 3/5+6, 7/5+6, 4/4+3, 3/3+2 — 9 variants available |
| Front Track | 1,565 mm |
| Rear Track | 1,508 mm |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2018 China VI |
Cargo Body & Special Configuration
| Cargo Body Type | Dropside cargo body; optional flatbed or chequer-plate cargo body appearance |
|---|---|
| Cargo Body Material / Weight | High-strength steel 553 kg / ordinary steel 558 kg / bamboo plywood 564 kg / steel-aluminium 550 kg |
| Side Panel Material / Thickness | DC01 steel 0.7 mm / Q235 steel 0.7 mm / DC01 steel 0.8 mm / Q235 steel 0.8 mm / bamboo plywood 13 mm / HC420LA steel 0.9 mm |
| Floor Material / Thickness | HC420LA steel 1 mm + B610L steel 1 mm / DC01 steel 1.2 mm + Q235 steel 1.2 mm / bamboo plywood 17 mm / HC420LA steel 0.9 mm |
| Side & Rear Guards | Side guard: Q235 and 6-series aluminium alloy, bolted. Rear under-run guard: HC700/980DP, D610 (6-series aluminium alloy), bolted |
| Rear Under-Run Guard | Section 100 × 50 mm / 100 × 75 mm, ground clearance 435 / 460 / 480 mm |
| Retro-Reflective Markings | Class I retro-reflective markings at the rear, Class II on the sides |
| ABS System | Hydraulic brakes: APG3550500A (Zhejiang Asia-Pacific Mechanical & Electronic Co., Ltd.); air brakes: CM4XL-4S/4M (Guangzhou Ruili Kemi Automotive Electronics Co., Ltd.) |
| Chassis-Mounted Options | Aluminium alloy wheel rims, aluminium alloy rear guards, aluminium alloy / carbon steel air reservoirs, long/short-arm exterior mirrors, carbon steel fuel tank, chrome front fascia, side markings, rear camera, etc.; optional without rear window glass, interior mirror, spare wheel, front fog lamp, front lower mirror |
| Other Configuration | Optional ETC on-board unit; kerb weight excludes the spare wheel, fire extinguisher, on-board tools and wheel chocks |
Engine
| Engine Model | JE493ZLQ6K / 4JD1 / 4JD1A |
|---|---|
| Manufacturer | Jiangxi Isuzu Engine Co., Ltd. |
| Displacement | 2,499 / 2,498 ml |
| Power | 93 / 113 / 105 kW (net power 91 / 110 / 102 kW) |
| Fuel Consumption | 11.5 / 10.4 / 10.4 L/100km (by engine model) |
Note: Data shown is taken from the published vehicle announcement for this model. Configuration varies by order; the specification sheet issued with the quotation prevails.
