HOWO 18t Refuse Compactor Truck

HOWO 18t Refuse Compactor Truck

The CL5187ZYS6HQ is an 18-tonne refuse compactor on a HOWO ZZ1187K511JF1 cargo-truck chassis with 2 axles and 6 tyres, at an 18,000 kg gross vehicle weight and 8,850 – 9,700 × 2,550 × 3,450 mm overall dimensions. The main equipment consists of a compaction body and a compression system used to collect, compact and haul municipal solid waste: refuse is tipped into the rear filler, compacted inside the body by the compression mechanism, and carried away at a much higher payload per trip. The vehicle uses only the 4,500 / 4,700 / 5,100 mm wheelbases, and can be specified with a square or curved body, a fully sealed cover, and different rear working equipment — bin-lift, skip loader, fully sealed hopper or swing-arm device (rear extension 200 mm with the sealed hopper or swing-arm, 400 mm with the bin-lift or skip loader). At a 10,790 kg kerb weight the rated payload is 7,080 kg (2-person cab) or 7,015 kg (3-person cab); at 11,750 kg it is 6,120 kg or 6,055 kg respectively. Side guards are Q235 carbon steel, bolted and welded, while the rear under-run guard is replaced by the special equipment with its lower edge 500 mm above the ground.
